Animal Care Horizontal Autoclave With Bio-shield Barrier Hermetically Seals

Good quality Hospital Steam Sterilizer for sales
Good quality Hospital Steam Sterilizer for sales
It is worthy to cooperate with Medpharm again. Also, prompt action on after sales service left me a deep impression.

—— Manusawee Wareesuwan

I like the sterilizer here running in our factory,it is wonderful.It is fully made to my requirement.Before that I contact many suppliers but they can

—— Marina.Stolyrova

I'm Online Chat Now

Animal Care Horizontal Autoclave With Bio-shield Barrier Hermetically Seals

China Animal Care Horizontal Autoclave With Bio-shield Barrier Hermetically Seals supplier
Animal Care Horizontal Autoclave With Bio-shield Barrier Hermetically Seals supplier Animal Care Horizontal Autoclave With Bio-shield Barrier Hermetically Seals supplier

Large Image :  Animal Care Horizontal Autoclave With Bio-shield Barrier Hermetically Seals

Product Details:

Place of Origin: China
Brand Name: Medpharm
Certification: CE
Model Number: MD-1.5

Payment & Shipping Terms:

Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Time: 30 working days after received your payment
Payment Terms: T/T in advance, LC AT SIGHT
Supply Ability: 10 pcs per month
Contact Now
Detailed Product Description
Working Temperature: 105 °c To 134 °c Application: Animal Laboratory
Sterilization Time Rage: 0---99 Minutes Chamber Material: SS304
Chamber Volume: 1500 Liters Test Programs: Bowie & Dick Test, Vacuum Test



Animal Care Horizontal Autoclave With Bio-shield Barrier Hermetically Seals

Quick details


  • Safe, Reliable And Economical
  • Chamber Volume Is 1500 Liters
  • Microprocessor Control, Simple and clear operation
  • Wide Offer Of Sterilization Programs
  • Working Temperature: 105 °c To 134 °c
  • Individual Job-Order Manufacture
  • Sterilization Time Rage: 0---99 Minutes
  • Vacuum Times: 0---9 Times
  • Drying Time: 0---99 Minutes


Applications

This series sterilizers are designed and manufactured specially to sterilizing medical instruments, sterile clothing, dressings, vessels, apparatuses, operating tools, culture medium etc.

Features



  • Motorized hinge door,single door autoclave, stable and easy to operation
  • Without built-in steam generator
  • Pneumatic valves
  • PLC, touch screen control, micro-printer recorder
  • With stainless steel cart and trolley
  • The material of chamber and jacket is SS304
  • The Bowie-Dick Test checks the effectiveness of removing air during the cycle
  • The Vacuum Leak Test checks the integrity of the chamber and piping system


Main Parameters


Model

Chamber Size

Overall Size

Net Weight

Steam

Water

Power

W*H*D mm

W*H*D mm

Kg

Kg/cycle

Kg/cycle

KVA

MD-0.24

600*600*670

1500*1800*1010

700

20

30

2

MD-0.36

600*600*1000

1500*1800*1340

800

25

40

2

MD-0.6

610*910*1170

1500*1900*1510

1250

30

60

3

MD-0.8

610*910*1450

1500*1900*1790

1400

35

80

3

MD-1.0

680*1180*1250

1600*2000*1590

1550

40

100

4

MD-1.2

680*1180*1500

1600*2000*1840

1950

45

120

4

MD-1.5

680*1180*1870

1600*2000*2210

2150

50

150

4.5

MD-2.0

1000*1200*1700

2000*2000*2040

2400

60

200

4.5

MD-3.0

1000*1500*2000

2000*2200*2340

2950

90

300

5

MD-4.0

1000*1500*2670

2000*2200*3010

3600

120

400

6

MD-5.0

1000*1500*3340

2000*2200*3680

4500

150

500

8

MD-6.0

1000*1500*4000

2000*2200*4340

5300

180

600

8

MD-8.0

1000*1500*5340

2000*2200*5680

6900

240

800

12


Programs

Test programs: Bowie & Dick test, vacuum test.
Working programs:  Multiple customizable programs for textiles, instruments, rubbers, culture
medium and liquids in unsealed bottles.

Main adjustable parameters



  •   Sterilization temperature rage: at 105°C to 134°C
  •   Sterilization time rage: 0---99 minutes
  •   Vacuum times: 0---9 times
  •   Drying time: 0---99 minutes



Multiple adjustable parameters to ensure user’s customized programs are available, accurate
and perfect sterilization effect.



Cycles


Cycle No.

Cycle Name

Further Details

1

Instruments/Tools

3 times Vacuum, expose temperature 132℃, expose time
8 min, drying time 5 min.

2

Clothing

3 times Vacuum, expose temperature 121℃, expose time
15 min, drying time 25 min.

3

Liquid

15 min exchange, expose temperature 121℃, expose time
15 min, cooling time 25 min.

4

B-D Test

3 times Vacuum, expose temperature 134℃, expose time
4 min, drying time 3 min.

5

Vacuum Leakage Test

Test the chamber connecting parts’ tightness effect. It’s
important to ensure the sterilization effect.

6

User Programmable

 All preset parameters can be resettable; Multiple customized
 programs can be set and stored by user.


Animal Care Horizontal Autoclave With Bio-shield Barrier Hermetically Seals

Brochure load down from here
Medpharm medical large steam autoclave brochure.pdf
