Payment & Shipping Terms:
|Door Type:||Hinge Door||Control System:||Siemens|
|Sterilization Medium:||Hydrogen Peroxide||Sterilization Temperature:||35-55*C|
1) Simple structure in linear type ,easy in installation and maintenance.
2) Micro-computer control, easy to operating and safety.
3) printing sterilization info during the process
4) Running in a high automatization and intellectualization,no pollution
5) The entrance has sterilizing filter..
1.complete sterilization in 17 minutes
2.No need for gas pipe& related device
4. Process temperature: 35-55*C
Plasma means that the highly ionized gas cloud. It is produced by gas under the function of heating or strong electromagnetic, mainly are electronic, hydronium, atom, active free radical, ray and so on. Among the active free radicals and rays, for example, the ultraviolet act as a strong role in the killing of microorganisms. Plasma is the nature fourth state in addition to solid, gaseous, liquid. Because its total number of positive and negative charges on the value of total number are always equal, so we called it PLASMA.
Sanqiang low temperature plasma sterilizer system is under the low temperature and negative pressure condition, impose high frequency in the sterilization room to ionization production plasma,acting on the cell walls of microorganisms, damage to the outer protective shell, then use hydrogen peroxide sterilizing agents killed thoroughly.
|SPECIFICATIONS FOR PLASMA STERILIZER|
|Technical parametrs /Model||SQ-D-60||SQ-D-80||SQ-D-100||SQ-D-130||SQ-D-220|
|Sterilization room size(cm )||60*35*28||60*40*30||70*40*35||75*45*40||85*52*50|
|Outer carton size (cm)||80*60*130||80*60*130||90*60*150||100*100*185||110*100*185|
|Standard sterilizing time (minutes)||50||50||50||50||65|
|Sterilization temperature (℃)||50±5||50±5||50±5||50±5||50±5|
|Total power (KW)||2.5||2.5||3||3||3.5|
|Installation evironment temperature||5-45°C||5-45°C||5-45°C||5-45°C||5-45°C|
|Minus install area (long*wide)cm||160*260||160*260||200*300||200*300||220*300|
|Minus distance with the back wall(cm)||10||10||10||10||10|
|Minus maintenance distance||two sides each one meter||two sides each one meter||two sides each one meter||two sides each one meter||two sides each one meter|
