Product Details:
Payment & Shipping Terms:
|
| Chamber Volume: | 35L, 50L, 75L, 100L | Material: | Made Of SS304 |
|---|---|---|---|
| Door Type: | Screws Locked / Unlocked Lid Style | Application: | Clinics, Laboratories |
| Feature: | Beep Alarm System | Type: | Vertical Steam Sterilizer |
| High Light: | 100L Medical Autoclave Machine,SS304 Autoclave Vertical Sterilizer,100L Autoclave Vertical Sterilizer |
||
Medical Autoclave Machine Price Mushroom Autoclave Vertical Sterilizer Autoclave Steam Sterilizer
1. Indicator light indicates working state
2. Over-temperature & over-pressure auto-protection device
3. Double scale indication pressure gauge
4. Safe protection of water lacking
5. With the below exhaust structure,which is convenient to exhaust the cold air
6. Automatically shut off with beep reminding after sterilization
7. Fully stainless steel structure
8. Easy to operate,safe and reliable
9. With two stainless steel sterilizing baskets
Specificaiton:
| Model | VT-35LD | VT-50LD | VT-75LD | VT-100LD |
| Volume | 35 Liters | 50 Liters | 75 Liters | 100 Liters |
| Sterilizing Chamber Volume | Ø318*H450 mm | Ø340*H550 mm | Ø400*H600 mm | Ø440*H650 mm |
| Working Pressure | 0.22 Mpa | 0.22 Mpa | 0.22 Mpa | 0.22 Mpa |
| Max Working Pressure | 0.23 Mpa | 0.23 Mpa | 0.23 Mpa | 0.23 Mpa |
| Working Temperature | 134°C | 134°C | 134°C | 134°C |
| Adjustment of Temperature | 105°C-134°C | 105°C-134°C | 105°C-134°C | 105°C-134°C |
| Timer | 0-99 minutes | 0-99 minutes | 0-99 minutes | 0-99 minutes |
| Heat Average | ≤± 1°C | ≤± 1°C | ≤± 1°C | ≤± 1°C |
| Power(AC220V,50Hz) | 2.5 KW | 3 KW | 4.5 KW | 4.5 KW |
| Overall Dimension(mm) | 480*460*850 | 520*520*980 | 560*560*980 | 590*590*1080 |
| Transport Dimension(mm) | 570*550*970 | 590*590*1110 | 650*630*1150 | 680*650*1220 |
| Gross Weight/Net Weight | 56kg/42kg | 68kg/50kg | 90kg/70kg | 105kg/85kg |
Application
The Vertical Cylindrical Pressure Steam Sterilizer is installed with an electrical heater, an automatically pressure-temperature controller, a safety valve, a releasing valve, a pressure-temperature indicator, an alarm bell for finished sterilization and an instrument to automatically cut off the power of heater. It has the advantages of effective sterilization, convenient operation, safe, less electro city consuming and cheap. It is ideal equipment for clinics, scientific research institutes and other organizations to sterilizer surgical instruments, fabrics, glasses, culture media etc.
